The UAV-Mounted Firefighting Water Gun is a lightweight aerial fire suppression nozzle designed for compatible unmanned aircraft and authorized emergency-response operations. It has a total nozzle length of 1,950 mm and a nozzle weight of 650 g. The system supports 25 mm or 40 mm water hoses and is supplied with a 100 m hose according to the source specification. It can be used with fire water or fire foam agents and provides a reported spray distance of 8-15 m. The recommended operating height is below 100 m. The hose, water or foam load and aircraft interface must be evaluated as part of the complete system before installation and operation.
Product Type
UAV-Mounted Firefighting Water Gun
Aerial Firefighting Water Delivery
Fire Water or Foam Delivery
The system supports fire water and fire foam agents, with a reported spray distance of 8-15 m. A 100 m water hose is listed in the source material, and the recommended operating height is below 100 m. Confirm the pump, hose routing, pressure, aircraft payload capacity and operating environment before deployment.
Lightweight Long-Pole Nozzle
The airborne fire water gun uses a long-pole nozzle with a total length of 1,950 mm and a nozzle weight of 650 g. It is designed to work with 25 mm or 40 mm water hoses and can be integrated with compatible UAV firefighting systems. The complete system load must include the nozzle, hose, water or foam agent and mounting equipment.
Technical Parameters
· Product Type: UAV-mounted firefighting water gun
· Nozzle Length: 1,950 mm
· Nozzle Weight: 650 g
· Compatible Hose Diameter: 25 mm or 40 mm
· Standard Hose Length: 100 m
· Firefighting Agent: Fire water or fire foam
· Spray Distance: 8-15 m
· Recommended Operating Height: Below 100 m
· Safety Measure: Automatic hose separation
· Application: Aerial firefighting and authorized emergency response
Want to Choose the Right Products for You?
Take a quick test to find the right propeller for you.
Aerial Fire Water Delivery System
· UAV-mounted firefighting water gun
· Nozzle length: 1,950 mm
· Nozzle weight: 650 g
· Supports 25 mm or 40 mm water hoses
· Standard hose length: 100 m
· Fire water or fire foam agent compatibility
· Spray distance: 8-15 m
· Recommended operating height: below 100 m
Packaging and Shipping
· Confirm whether the package includes the 100 m hose, mounting hardware and connection fittings.
· Confirm the complete operating-system weight, including the nozzle, hose, water or foam agent and aircraft mount.
· Confirm the pump, hose connection, pressure and aircraft interface before quotation.
· Final package contents, transport method and shipping requirements should be confirmed with RAYI.
Need a Custom
Share your UAV requirements. We’ll help evaluate the right propeller solution.
Important Firefighting Integration Notes
· The 650 g specification refers to the nozzle only and does not include the hose, firefighting agent or mounting system.
· Confirm the aircraft payload capacity, center of gravity and hose-routing requirements before installation.
· Confirm compatibility with the selected 25 mm or 40 mm hose, pump and firefighting agent.
· Keep the UAV, hose and water or foam supply clear of rotors, propellers and moving structures during operation.
· Use only in authorized firefighting or emergency-response operations with trained personnel.
· Confirm local aviation, water-discharge, fire-safety and environmental requirements before deployment.
